Cylindrical lithium battery, square lithium battery and soft pack lithium battery which power is better?

Introduction

Lithium batteries introduction is one of the crucial steps in the battery technology evolution. Lithium batteries replace leady, big bulky lead-acid batteries. They feature better capacity and stay with Li-ion battery systems.

The lithium-ion battery dominates lead-acid batteries, the traditional options. The technology of lithium batteries is well-known among different lithium battery types available in the market to suit various needs and applications.

Lithium batteries create electric current with the lithium ions movement between anode and cathode materials and are rechargeable batteries. The materials used are lithium-based compounds, and the electrodes vary as per the lithium battery technology. During the process of charging, the lithium ions move to the anode from the cathode, and while discharging they move vice-versa to the cathode from the anode.

Lithium-ion Battery Types

Lithium-ion batteries are in three types cylindrical, square, and soft-pack lithium battery. Their safety performance, weight, capacity, and cycle life are different.

There are different lithium-ion types of batteries, and they vary in characteristics drastically. Thus, the lithium-ion battery is as per its requirements and meets purposes specifically. The properties of lithium-ion batteries vary with battery manufacturers significantly. Generally, lithium-ion batteries last for 5 to 6 years, and manufacturers provide a warranty policy assuring the battery lasts longer.

cylindrical lithium battery

Cylindrical lithium battery has mature technology and the longest development time. It features standardization to a high degree.

Safety-?The cylindrical battery features more space between batteries and offers enough space during heat dissipation. It is the reason that cylindrical battery is in many models and endures a low-cost technology of air cooling.

3.2V 20A Low Temp LiFePO4 Battery Cell -40℃ 3C discharge capacity≥70% Charging temperature：-20~45℃ Discharging temperature: -40~+55℃ pass acupuncture test -40℃ maximum discharge rate：3C

READ MORE

Weight-?The hassle of cylindrical lithium batteries is their excessive number. A high energy density battery is essential for a vehicle, implies the need for cylindrical batteries in thousands. When all these are together, the requirements for the battery management system become higher. Besides, the cylindrical lithium battery requires a steel shell to assemble as a battery pack, and the weight is high. However, the energy density is low of the cylindrical battery than square and soft pack lithium batteries.

Capacity and cycle life-?A lithium-ion battery offers 10C continuous discharge. It provides a 20A continuous load at 2000mAh. The average life span is 300 to 500 charge cycles or 2 to 3 years, whichever is first. Charging cycle utilization duration is when the battery is fully charged, or drains completely, and it needs complete recharging. Undoubtedly, most lithium-ion batteries survive longer for over 10-15 years, and the batteries last thrice as lead-acid batteries. The lithium-ion rechargeable batteries feature a finite lifespan and lose slowly their ability to retain the charge. The reduction capacity is permanent, and it reduces with time.

Square lithium battery

Square lithium battery is prominent for its lightweight and simple structure.?Their safety performance, weight, capacity, and cycle life details are:

Safety- Square lithium batteries are different in material, structure, and reaction from cylindrical lithium batteries. These affect the protection measures and safety of the battery. Square lithium batteries use metal shells and assure safety like cylindrical batteries. With battery temperature rising abnormally, there is high resistance with square lithium battery, which hinders the charging and discharging of battery current to ascertain battery safety. The square lithium batteries will soon become the power batteries mainstream.

Weight-?Square battery is in the shell hardness and features a lightweight technology development. It provides superior performance in the market.

Capacity and cycle life-?The square batteries do not use steel shells so the energy density is higher, comparing the cylindrical battery. The square batteries feature customization, so the production of square batteries is not easy, and the standardization degree is low. These square batteries are popular in China, and it is because of their simple structure.

Low Temperature High Energy Density Rugged Laptop Polymer Battery Battery specification: 11.1V 7800mAh -40℃ 0.2C discharge capacity ≥80% Dustproof, resistance to dropping, anti - corrosion, anti - electromagnetic interference

READ MORE

Soft pack lithium battery

Soft pack lithium battery is flexible and known for its battery layout. Here are the details of its safety, weight, capacity, and cycle life:

Safety-?The soft pack lithium battery is smaller in size, and features a flexible battery layout in comparison to the other two battery types. It adopts the superimposed method of manufacturing and has a slimmer volume, ensuring the highest energy density. The soft-pack battery features less leakage of electrolytes. It swells and cracks, if there is too high internal pressure, instead of exploding.

Weight-?The soft pack battery is lighter in weight by 40% in comparison to the steel square battery in the same capacity and lighter by 20% than the aluminum square battery. The positive and negative material used in the soft-pack batteries does not bring a huge weight difference in steel and aluminum shells. The actual difference is about the flexible packaging materials and polymer electrolytes. They have technically complicated materials. Nowadays the passenger car battery materials are square and cylindrical, which means the soft package battery brings a breakthrough in the future.

Capacity and cycle life-?Soft pack lithium battery requires adding between every set of two batteries, a thin layer, and is full of liquid. The working temperature is at optimum by cooling or heating. The batteries need sophisticated control systems. The cycle life of soft pack lithium battery is longer, and 100 cycles attenuation is 4% to 7%, much less than aluminum case.

Wrapping Up

Lithium-ion batteries, cylindrical, square, and soft-packed batteries are in use in the current market. As such, there is no real difference between bad and good. Each has its pros and cons. The soft pack battery has the highest cell energy density, following it is the square battery, and the smallest is the cylindrical battery.

?Lithium-ion batteries at present include cylindrical, square, and soft-pack batteries. They are made of stainless steel, aluminum alloy, and hard shells, while soft-pack has aluminum-plastic film. All three lithium battery types are manufactured in different enterprises, and it may be due to valid reasons. It may be the product technology or anticipating the battery market's future power. However, each battery type market field dominates such that the square battery that is high energy density will transform as branch esteems, and the cylindrical battery benefit is to become dominant, leading the market development and selection.
