Advantages and disadvantages of lithium cobalt oxide battery

Lithium cobalt oxide battery has stable structure, high specific capacity and outstanding comprehensive performance, but its safety is poor and the cost is very high. It is mainly used for small and medium-sized batteries. It is widely used in small electronic devices such as notebook computers, mobile phones and MP3/4. The voltage is 3.7V.

Characteristics of lithium cobalt oxide battery

1. Excellent electrochemical performance

2, excellent processing performance

3, the tap density is large, which helps to increase the battery volume ratio

4, product performance is stable, good consistency

Advantages and disadvantages of lithium cobalt oxide batteries

Advantage

1, stable structure

2, high capacity ratio

3, excellent process performance

4, volume energy density

Disadvantage

1, poor security

2, the cost is very high

3, the cycle life is general, the material stability is not very good

Lithium cobalt oxide battery has stable structure, high capacity ratio and outstanding comprehensive performance, but its safety is poor and the cost is very high. It is mainly used for small and medium-sized batteries. It is widely used in small electronic devices such as notebook computers, mobile phones and MP3/4. The voltage is 3.7V.

Characteristics of lithium cobalt oxide battery

1. Excellent electrochemical performance a. The average capacity attenuation per cycle is <0.05% b. The first discharge specific capacity >135mWh/gc.3.6V initial discharge platform ratio>85%.2, Excellent processing performance 3, High tap density Help to improve battery volume ratio capacity 4, product performance is stable, good consistency Product model R747 tap density 2.4-3.0g/cm3, typical value is 2.5, particle size D506.0-8.5um; R757 tap density 2.4-3.2 g/cm3, typical value is 2.6, particle size D506.5-9.0um; R767 tap density is 2.3-3.0g/cm3, typical value is 2.5, particle size D508-12um;

Use of lithium cobalt oxide battery

It is mainly used as a cathode material for the manufacture of lithium ion batteries for mobile phones and notebook computers and other portable electronic devices.

Technical standard for lithium cobalt oxide

1. Name: Lithium cobalt oxide battery Molecular formula: LiCoO2 Molecular weight: 97.882, main use: lithium ion battery 3. Appearance requirements: gray black powder, no agglomeration 4, X-ray diffraction: control JCDS standard (16-427), no impurity phase Existence 5, packaging: plastic bag packaging in iron drum 6, chemical composition and physical and chemical properties: nickel Ni 0.05% max (wt%) manganese Mn 0.01% max (wt%) iron Fe 0.02% max (wt%) Calcium Ca 0.03% max (wt%) sodium Na 0.01% max (wt%) acidity alkaline pH 9.5-11.5 water content (105 & ordm; C dry weight loss, %) Moisture (wt% lossat105 & ordm; C) <0.05 Specific surface area (m2/g) BETsurfaceArea (m2/g) 0.2-0.6 tap density (g/cm3) TapDensity (g/cm3) 1.7-2.9 particle size-D50 (μm) PSD-D50 (μm) 5-12 Particle size - D10 (μm) PSD-D10 (μm) 1-5 particle size - D90 (μm) PSD-D90 (μm) 12-25

The application of lithium cobalt oxide battery is still relatively small. The technology of cobalt lithium for small batteries is very mature, but the cost of cobalt lithium is too high. Many companies use manganese lithium instead, and some are manganese lithium. Lithium cobalt oxide battery has stable performance. Currently, the technology used in mobile phones is the most mature, but the biggest disadvantage of application is high cost. Cobalt is a scarce strategic metal. In addition, it is also difficult to apply to power batteries.
