Comparison of nickel-cadmium battery and lithium battery

Nickel-cadmium battery used as a traditional train

Advantage

1. High safety performance, can be overcharged or over-discharged

2. High temperature performance, the temperature range is -20 ° C ~ 60 ° C, within this range can be discharged.

3. Affordable, the number of cycles is about 500 times

Disadvantage

1. Low energy density.

2. Nickel cadmium is a heavy metal that pollutes the environment.

3. The memory effect of the nickel-cadmium battery, after repeated several times to maintain the low-capacity discharge, the battery will not work if a larger amount of discharge has to be made.

4. The battery needs regular maintenance, such as adding electrolyte.

5. The self-discharge rate is too large, and the nickel-cadmium battery is 15 to 30% (month).

Lithium battery

Advantage:

1. High security, not overcharge and over discharge, need to support BMS battery management system.

2. High temperature and low performance, the temperature range of -20 ° C ~ 60 ° C can also be used even -40 degrees can also be low rate discharge.

3. High energy density, the current technology is about three times that of nickel-cadmium batteries. The number of charge and discharge is 3,000 to 10,000 times.

4. Little impact on environmental pollution.

5. Free regular maintenance.

6. The self-discharge rate is small. The lithium battery is 2 to 5% (month).

Disadvantages:

The current procurement cost is higher than that of nickel-cadmium batteries. According to the development of the industry and the expansion of production capacity, there is room for continuous price reduction.
