A LiPo battery or lithium polymer battery or lithium-ion polymer battery is a type of rechargeable battery based on the lithium-ion technology utilizing a polymer electrolyte. These types of batteries are known to provide higher specific energy as compared to other types of lithium battery. Plus, they are used in those applications where the critical characteristic is weight, for instance, mobile devices.

If you are wondering about what is LiPo battery connector, then you have come to the right page. Here, you will get to know everything about LiPo battery connectors and what’s its intended purpose.

However, it doesn’t matter whether you are using LiPo battery for planes, radio control applications, or anything else, choosing a right connector is a really big deal. If you end up choosing a poor connector, then it can probably lead to further complications in your application. In order to purchase the right battery connector, you need to first understand about connector in detail.

So, let’s begin to explore what heck is LiPo Battery connector…

LiPo Battery Connectors Explained

The LiPo battery connector is nothing, but a simple device used to join electric circuits together. Most battery packs which include LiPo need more than one connector. However, the primary battery connector is the mechanical as well as the electrical part that is responsible for interfacing the battery to the electric device. The hunt for proper and right LiPo connector can start from based on its intended purpose and size.

If you are using a smaller LiPo battery, then you are going to need a smaller connector and that’s also a too obvious thing. Similarly, if you are using a larger LiPo battery, then you are going to need a larger connector. Also, wire size is included. It means that if you are using a tiny 20awg wire that is soldered into a 6mm bullet, then the solder joint will have a higher possibility of cracking due to the weight of the battery connector itself.

Correspondingly, if you are using a large 6s 10,000 mAh battery along with 10AWG wiring, then a small 3mm bullet connector will be too small for the packing. Once you realize these factors, you can begin with your hunt for choosing the right LiPo battery connector for the application.

At present, the term “RC LiPo battery connectors” is quite famous. The goal of all these connectors is straightforward and they provide an easy and simple way to connect the RC LiPo battery packs into power system in order to complete the electric circuit, enabling the current to flow from the LiPo battery to system and its other components.

Also, keep in mind that the connection must be solid, reliable and capable of passing sufficient current in order to meet the maximum current requirement of the application. If the connector fails to pass sufficient current, then it could cause overheating or lead to the voltage drop.

Well, overheating occurs only if the excessive current condition lasts for a nonstop time period. On the other side, a voltage drop occurs can also lead to further bad things in your application. Thus, the first and most important thing you need to understand when it comes to choosing the right LiPo battery connector for RC powering application is the quantity of current it can draw.

LiPo Battery Connectors Types

There are different types of LiPo battery connectors are available out there. It is quite important to know about types if you want to ensure that you are choosing the right connector.

· Deans connectors

Deans connectors are the industry standard without any doubts. They have been in the market for a long time and have been the first choice for RC enthusiast. The best part of these connectors is that they are capable of sliding together smoothly and comes with a decent design. Like other modern connectors, this type is also polarity protected.

However, they can be hard to solder, especially for newbies.

· Bullet connectors

Bullet connectors are quite the main connectors connected to most LiPo batteries, particularly the larger LiPo batteries. The best part of these connectors is that they are capable of handling a high current load. But, they can pull apart if handled roughly.

· Traxxas connectors

Traxxas connectors are known as high current type of connectors. While these connectors are generally famous in RC cars and trucks, there are some airplane enthusiasts who prefer using these connectors too. One of the reasons is because they are quite easy and simple to assemble. They are also polarity protecting.

· XT-60 connectors

XT-60 connectors are a little bit expensive than other LiPo battery connectors available in the market. However, they are very famous and the most common types of connectors used. The best part of these connectors is that they are very prevalent, easy to solder and compact. Thus, all these traits make them the right choice for RC enthusiasts.

· Servo connectors

Servo connectors are an easy-to-use and common type of connector available out there. But, these types of connectors work great only under low current, and it means that they aren't the best choice for all purposes. Although it is the most recommended choice for LiPo battery connection, these connectors are a good option for camera and video transmitter wiring.

LiPo Battery Connector Adapters

If you are thinking about buying a LiPo battery connector, then you may probably have good soldering skills. But, if you are not good when it comes soldering, then you should think twice about purchasing LiPo battery connector. Plus, it is recommended that you should buy custom-made adapters having pre-soldered cable adapters. This will make quite easier and easier for you to connect any type of LiPo battery connector to a wiring of the model.

However, make sure that the type of connector you are going to choose should meet your particular connection needs.
