Tell me more about DIY 18650 battery charger

The world is being shifted much away from fossil fuels and soon it will become entirely electric. At the present day, batteries are being used most commonly in almost each of our electronic devices which can be ranged from laptops to our handheld devices. More importantly, batteries which are based on Lithium-ion have become more promising among all other battery types. Even more, the battery packs which are being used in?Laptops, Drones, RC Toys, Medical devices, e-bikes, electric cars (EV) and Power tools are based on 18650 batteries format. As the lithium-ion batteries are playing an important role as the best energy storage solutions for modern consumer products because these have the ability to be recharged again. 18650 is one of the best and most matured Lithium-ion battery formats which is available at present. It has the ability to let you enjoy high volume at a low cost per Wh.

In order to maximize the efficiency, effectiveness and performance of 18650 batteries which are based on lithium-ion, a high-quality and best charger are required. The most important functionalities which must be available in the high-quality charger of 18650 battery include long cycle life and high charging efficiency.

Design of 18650 battery charger

When it comes to having a look at the design of 18650 battery, then you will get an idea that it comes with a diameter of 18mm and 65 millimeters length. However, when we talk about the 18650-battery charger, then you must know the proper design methods could limit the current amount which can be drawn from the port to meet specifications. the visual design of the charger is quite simple. However, to design a DIY charger, 18650 batteries can be perfect for the job. Even more, you will need some simple power input, battery holder to design your own charger perfectly. It hardly takes 10 minutes to complete the process of designing your DIY charger with available components.

Advantages of DIY 18650 battery charger

It is really easy to understand the fact that why 18650 batteries are being used everywhere. For sure the battery life. It is because the 18650 batteries have the ability to be recharged for a longer period of time with ease. Their actual charging times are truly bigger. Therefore, when it comes to the 18650 chargers then it is highly important to pay attention to some details and must have a look at the benefits which are associated with the 18650-battery charger. So, when you think about the 18650 batteries chargers then the most common option which you can get for this is a DIY charger. It is because there are several benefits which are associated with this that makes a DIY 18659 battery charger a preferable option to having.

Do you want to know what advantages can come with a DIY 18650 battery charger? Well, here are some of the most amazing advantages which you must know to get a better idea about the things in the best possible way. Have a look at the following advantages:

Prevent battery damage

A DIY 18650 battery charger has the ability to prevent battery damage. It is because most of these chargers have the ability to stop charging when the battery gets full. This is one of the best things which can make a DIY 18650 battery charger the best to use to get your 18650-battery recharged with ease. Even more, it will provide a constant current and voltage to the battery which makes it faster to get recharged.

Perfect for travel

When you have to travel around a place where it could be difficult for you to get your device charged, then bringing a DIY battery charger can be an amazing option to utilize. This is one of the best things which can stay with you even in long traveling too.

Easy to use

There are no hard and fast rules to use these DIY chargers. It is because the interface of DIY 18650 charger is quite simple and you just have to plug-in charging wire in its port to start charging. ?

Cost-effective

To prepare a DIY 18650 battery charger you do not have to spend a lot of money which makes it an affordable option to have. Even, the durability of these chargers also makes them the best option to have.

Multiple charging ports

Most of the DIY 18650 chargers come with multiple charging ports which will help you to charge multiple batteries at once with ease.

How to prepare a DIY 18650 battery charger?

1.To start the process of making a DIY 18650-battery charger, you have to Required components

· 3.5 by 4.5 Inches wooden piece.

· 18650 batteries

· TP4056 Charging Modules

· 18650 battery Holder

· Double Sided Tape

2.At first, you have to add tape on the backside of your 18650-battery holder and TP4056 charging modules.

3.Now, you have to take the wooden piece and place the 18650-battery holder on the wooden piece in a proper way (double-sided tape which you have placed beneath battery holder will let you stick it on wood with ease).

4.Now this is the time to take TP4056 charging modules and place them above the battery holder which you have placed before.

5.Now Solder the negative wire of the holder with the equivalent negative pin and similarly attach the positive wire with the corresponding positive pin in a proper way.

6.Now take the 18650 batteries to put into the available slots of the battery holder.

Note: While buying the 18650 batteries it is always important to pay more attention. It is because you can find multiple types of 18650 cells in the market available with different price ranges. It is highly recommended to buy the 18650 cells of a well-known company. It is because these come with excellent performance and quality control characteristics.

7.Once you have done with this process, now it is time to test your DIY battery charger. Check every port to ensure it is working properly.

After you have done testing,?congratulations, you have built your DIY 18650 charger successfully. The process is quite easier and it will not take much time to design your own DIY 18657-battery charger.
