LiPo Battery On Off Switch-How to Use

A LiPo battery is also known as lithium polymer battery and it is a type of rechargeable battery based on lithium-ion technology that uses a polymer electrolyte over a liquid electrolyte. LiPo batteries offer higher specific energy as compared to other types of lithium battery available out there. More importantly, they are used in those applications where the critical feature is weight, for instance, radio-controlled devices and mobile devices or smartphones.

In short, we can say that LiPo batteries are one of those batteries that are used in most consumer applications. They have gained huge popularity because of the benefits they have - lighter weight, higher capacities, and higher discharge rates. Those people who use or familiar with LiPo battery often may have heard the term “LiPo battery on/off switch”. If you’re using LiPo battery, then isn’t, it so? But, many people don’t know about what is the purpose of LiPo battery on/off switch. This post is all about LiPo battery on/off switch, how to use it for different applications and tips to protect it.

So, let’s begin-

Functions Of LiPo Battery On-Off Switch

Well, LiPo batteries generally come pre-attached along with a two-pin JSP-PH male connector, which slots straight into a JST-PH jack on whatever application requires powering. This is suitable or appropriate for permanently on applications. However, there are some people who would like to turn their applications on/off by connecting and disconnected the power respectively from the battery. That’s when LiPo battery on and off switch role comes in.

Therefore, it means that the main function of a LiPo battery on/off switch is to connect and disconnect the power from the battery whenever you would like to. Generally, one side of LiPo battery on/off switch is connected to the -ve (negative) terminal of a JST-PH male connector. And the other side of the LiPo battery on/off switch is connected to the -ve (negative) terminal of a JST-PH female jack. Moreover, the +ve (positive) terminal of the JST-PH male connector is wired directly to the +ve (positive) terminal of the JST-PH female jack.

Battery switch has an indicator that tells whether it’s “on” or “off” position. Also, there are some battery switches comes with an LED indicator that indicates you what amount of power is left in your battery pack.

If you are quite familiar with the world of the battery, then you can make battery switch on your own. However, it’s still recommended that you should purchase the switch if you want. You can easily find so many manufacturers online who sell battery switch, especially for LiPo technology at an affordable rate.

What On/Off Switch To Use For Different Applications?

Without a doubt, a switch plays a vital role when it comes to controlling power. And a switch is nothing, but devices used to turn on and off the application. There are several types of on-off switch available out there to use for different applications, which include

· Single pole single throw - the SPST include two terminals - one input terminal is called pole and another output terminal is called throw and that’s why the name is single pole single throw. It is one of the simplest switches.

· Single pole double throw- the SDPT includes three terminals - one input terminal, and two output terminal (throw). This switch can supply signal or current to two loops and it is also called selector switch.

· Double pole single throw - the DPST includes four terminals - two input terminals and two output terminals. They are used when you would like to control two circuits at the same time.

· Double pole double throw - the DPDT contains six terminals - two input terminals and two terminals for every pole and four output terminals.

There are also other types of on/off switch use for different applications. However, battery on/off switch is installed and used in an electrical system that enables the operator to fully disconnect electrical current or power running via an application.

The main thing you need to know about what’s the importance of a battery on/off switch-short circuit protection, safety and save costs. With a battery switch, you can prevent expensive battery replacements and make sure that the battery is completely charged for your next job. More importantly, most switch units that will detect low LiPo voltage and thus, cut off power in order to protect your battery from over-discharging. Also, if you’re planning to buy LiPo battery on/off switch online, then you should make sure to choose the trusted and reliable manufacturer.

How To Protect LiPo Battery On Off Switch?

Oh, finally - you have purchased LiPo Battery On Off Switch or make your own battery switch at home. Now, the next main concern is what you can do for its protection. Isn’t, it right? Well, you will be glad to know that there are several things you can try to protect your LiPo Battery On-Off Switch.

· Generally, whenever you purchase any item, you get an instruction manual that guides you on how to use purchased item in the right way. Most people ignore it or don’t pay much attention to that manual. But, reading it can help you to give an idea of how to use LiPo Battery On Off Switch appropriately.

· We can all agree that LiPo batteries are also potentially dangerous. Therefore, it is vital that you never leave these batteries unattended during charge.

That’s all on LiPo battery on/off switch. We hope that our guide has helped you to get an idea of battery switch working.
