Electrical performance laboratory

Mainly for the finished battery pack charge and discharge performance, overcharge and over discharge detection, volume test, smart battery learning test. Suitable for battery testing of lithium ion batteries , nickel metal hydride batteries, lead acid batteries, carbon batteries, alkaline batteries, lithium manganese button batteries. Constant voltage, constant current, constant resistance, and cycle modes can be set separately. Powerful, computer software control, single point, multi-point control, complete interface type, efficient and safe. Data collection, report production and integration. There are blue-chip lithium battery sub-container, rechargeable battery sub-container, Xinwei, Ruineng aging test cabinet, primary battery automatic discharge detection cabinet and other testing equipment. Some instruments are introduced as follows:

BK-3512L / 2 Blue- lithium battery into automatic detection equipment:

mainly used for a lithium ion battery formation, the capacity of matching points pairs, and the charging and discharging cycle life test, to ensure monomers, especially multi-parallel combined overall performance of the battery. Features of the instrument:

1> Double-sided structure, the whole cabinet can test 512 single-cell lithium-ion batteries. Each battery has a completely independent constant current and constant voltage source, and the self-forming loop does not affect each other.

2> Optional internal resistance test function, can test the internal resistance of each station battery, and is used for battery sorting.

3> With a variety of hardware protection functions: sampling line disconnection protection, upper and lower voltage overvoltage protection, leakage protection.

4> The software is powerful and easy to operate. It can realize the functions of centralized measurement and control, data processing and report making of the device, and has various protection functions such as voltage abnormal protection, current abnormal protection, over capacity protection, constant voltage charging voltage fluctuation protection. .

5> The software has a variety of battery inspection interfaces, which can save the complete charge and discharge data and curve of each battery. The battery can be sorted and counted according to various parameters such as capacity, time, open circuit voltage, platform time and internal resistance.

6> With data power-down protection.

7> The upper computer can set up to 64 steps and 256 cycles.

Xinwei high-precision battery tester BTS-5V6A:

Mainly used for battery cycle life test, capacity test, charge and discharge test, convenient fixture and strong versatility. It is suitable for performance testing of lithium polymer, lithium ion, nickel hydrogen, nickel cadmium, lead acid and other batteries, chemical and small capacity battery production and capacity sorting, combined battery and laptop battery testing. Features of the instrument:

1> The system hardware is stable and reliable, each channel has independent constant current and constant voltage source, independent control, and does not interfere with each other;

2> has various charging and discharging modes: constant current, constant voltage, constant current and constant voltage charging. , constant current, constant power, constant resistance discharge;

3> cycle measurement range: 1~9999 times, single cycle step number up to 64 steps, with loop nesting function
