Batteries have become the most important source of electrical energy. Your car will not start without a battery. Your mobile device will not operate without a battery. Many portable electronic devices we have today need batteries.
How much do you know about batteries, though? Many people only know them as parts of the devices that produce power.
It’s important to know as much about batteries as possible. This means understanding different components and what they are made of.
In this guide, we are focusing on battery terminals. What are they, how are they made, and their use?
What Is a Battery Terminal Called?
Every battery is different in its contraction. However, they have certain features that are common to all. One such feature is the terminals.
Terminals is a common term. Think of the railway terminals. This is the section that connects different routes of the trains.
Battery terminals operate similarly. We can simply call them the connections. They are responsible for connecting one side of the battery to the other.
Take any battery and have a close look? You will notice that no matter their size, they have two terminals. In some batteries, they are set on either side. In other batteries, terminals are much closer – but they are always connected separately.
One terminal is always marked (+). This is the positive terminal. The other negative terminal is always marked (-).
When you look at normal batteries like AA, C, and D, you will find the terminals on either end. Car batteries or 9-volt batteries are a bit different. You will see the terminals at the top of the unit.
Connecting a wire between the two causes electrons to flow from the negative to the positive terminals. This can be dangerous, especially with large batteries. You must connect it to a load, something like a light bulb, a motor, or an electronic circuit.
The Electrodes
A battery comes with internal components housed in a metal or plastic case. Inside the case, you will find two important elements, the anode and the cathode.
The cathode connects to the positive terminals. Hence, this terminal is also called the cathode.
On the other side, if the anode is connected to the positive terminal. The terminal can also be called the anode.
These two components are collectively called electrodes. They occupy most of the space inside a battery. This is because most chemical reactions produce electrical current into the load.
Electrodes inside a battery should never get in contact. It causes a severe reaction that can lead to an explosion. There have been many cases of batteries exploding because of this effect.
To avoid such instances, separators are used. It creates a barrier between the cathode and the anode.
Inside the battery, there is also the electrolyte. This is the medium that causes electric charges to flow between the terminals.
A collector is a component that conducts the charge to reach outside of the battery. It also plays a vital role in how the electrodes operate.
What Is a Battery Terminal Test?
As you can see, battery terminals play a key role in electrical conductivity. It would be impossible for your device to work without a proper connection.
Generally, batteries are suitable for power storage and use. Sometimes, however, they fail to work effectively. You will then need to check what the problem might be,
One of the main components to check is the terminals. A terminal test should be done if you are sure the battery is new yet it still fails to perform.
This test quickly checks for poor electrical connection between terminals. The battery cables should always be in good working condition. Without this, it’s hard to get full performance from the battery.
For this test, you will require a voltmeter. This measures voltage drop across terminals and the cables. It will indicate whether or not there is a proper flow of electrons.
When a battery is fully charged, there is a specific expectation of how much power it must give. When this does not happen, something could be wrong with the terminals.
You don’t need to be an expert to perform a terminal test. All you need is a voltmeter and some knowledge of using it.
How to Perform a Terminal Test
Performing a terminal test on a battery is relatively easy:
With a voltmeter, start by connecting the negative of the voltmeter lead on the end of the battery cable. Ensure this connection is well set in place.
Touch the positive lead to the terminal of your battery.
Ensure the ignition or injection system is disabled to keep the engine from starting.
Crank the engine with an eye on the voltmeter reading.
Note the reading on the voltage meter. If the reading is 0.5, the battery cable connection is facing high resistance. You need to clean the battery connections.
?Good and clean terminals will give readings of less than 0.5 drop. And that will also mean good performance in your battery.
What Is a Battery Terminal Made Of?
The plates inside a car battery are made from lead. This is the same material you will find on the terminals. Lead is one of the strongest materials in terms of corrosion-resistant.
You may have noticed that cleaning battery terminals is quite easy. Use baking soda and water, and all carbon or rust will be gone. It’s all in the material.
Note, however, that there are different types of terminals. The common type is the top-side terminal posts. These ones look like pegs.
There are other options. They include side terminals with cable connections screws. Then there are L-terminals that are set on top of the battery case with bolts to secure them in place.
When you want to replace the terminals, always keep in mind lead. You can purchase steel terminal posts too, but these are less conductive. They can also cause a misdiagnosis showing a low battery charge even when it’s full.
Lead is highly malleable, apart from being great conductors. They make putting the terminals in place much easier.
