Project number: 04DQ0090-02
Cell model: INR18650-26A/2600mAh/3.6V
Battery specification: 18650-3S3P/7800mAh/10.8V
Nominal voltage: 10.8V
Nominal capacity：7800mAh
Charging voltage: 12.6V
Charging current: ≤3.9A
Discharging current: 7.8A
Instant discharging current: 8.0A
End-off voltage: 7.5V
Internal resistance: ≤250mΩ
Battery weight: 600g
Product dimension: 23.5*99*140mm
Charging temperature：0～45℃
Discharging temperature: -40～60℃
Storage temperature: -20～35℃
Intelligent lithium ion battery protection: electric power management, short circuit protection, overcharge protection, over discharge protection, over current protection, etc.
Application field: toolbox
