18650 14.4V 6000mAh Samsung Battery for Crane

Product number: 36AQ363-01

Cell model: 18650/3000mAh/3.6V

Battery specification: 18650-4S2P/6000mAh/14.4V

Nominal voltage：14.4V

Nominal capacity：6000mAh

Charging voltage: 16.8V

Charging current: 3000mA

Discharging current: 1200mA

Maximum discharging current: 6000mA

End-off voltage: 11.0V

Internal resistance: ≤200mΩ

Battery weight: 1000g

Product dimension: 120.5*131.5*61.0mm（Max）

Charging temperature：0～45℃

Discharging temperature: -30～65℃

Storage temperature: -20～60℃(less than a month)

Battery case: cold rolling and metal plate

Lithium ion battery protection: short circuit protection, overcharge protection, over discharge protection ,over current protection, etc.

Application field: machinery and equipment

Product features

1.Battery management: using TI charging management chip, with high stability, high precision monitoring, precise control, temperature protection and other functions, which can eliminate the potential safety hazard to the maximum extent.

2.Cold rolling and metal plate: Increase the reliability and firmness of the battery.

3.Data communication management: It has communication transmission, accurate data transmission, precise temperature control, real-time battery condition monitoring and control.

4.Aviation plug output mode is adopted to increase the conductive reliability.

5.The battery pack has good security and nice performance.

6.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
