Low Temperature Charge and Discharge 25.6V 20Ah Robot LiFePO4 Battery

Product number: JDM-2078-01

Battery model: JD2270160CFL(3.2V-20Ah)

Battery specifications: JD2270160CFL-8S1P-25.6V-20Ah

Product size: 204*173*89mm

Nominal voltage: 25.6V

Nominal capacity: 20Ah

Charging voltage: 29.2V

Charging current: 10A

Discharge current: 15A

Discharge cut-off voltage: 16V

Finished internal resistance: ≤180mΩ

Battery weight: 4.8Kg

Charging temperature: -20°C~+45 °C

Discharge temperature: -30°C~+60 °C

Storage temperature: -20~+50℃ (less than 1 month); -20 ~ 40 ℃(less than 3 months); -20~+20℃ (less than 6 months)

Battery package: PVC heat seal process

Output mode: national standard UL wire

Communication management: RS485 communication protocol

Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, overtemperature protection, etc.

Application: Robot battery
