12.8V 20Ah Intelligent Video Surveillance Lithium Iron Phosphate Battery

12.8V 20Ah Intelligent Video Surveillance Lithium Iron Phosphate Battery
12.8V 20Ah Intelligent Video Surveillance Lithium Iron Phosphate Battery
12.8V 20Ah Intelligent Video Surveillance Lithium Iron Phosphate Battery
12.8V 20Ah Intelligent Video Surveillance Lithium Iron Phosphate Battery

Product Detail

Product number: 05DQ0068-04

Cell model: C40-20Ah-3.2V

Battery specification: C40-4S1P-20Ah-12.8V

Product size: 142*82*82mm

Nominal voltage: 12.8V

Nominal capacity: 20Ah

Finished internal resistance: ≤120mΩ

Charging voltage: 14.4V

Charging current: ≤5.0A

Discharge current: ≤5.0A

Discharge cut-off voltage: 8.8V

Battery weight: 1500g

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ~ 35℃

Battery package: Blue PVC heat shrink film

Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overtemperature protection, overcurrent protection,ESD protection, etc.

Applications: power/national road and other intelligent video surveillance equipment, security equipment


Product Features

1.Blue PVC heat shrink film package is simple and reliable,and easy to install;

2.The battery pack is laser welded with special nickel sheet, which has good vibration resistance, shock resistance and connection performance.

3.Adopt MOLEX plug output mode to increase electrical conductivity reliability;

4.Use special lithium battery protection chip, with high stability, high precision monitoring, precise control, temperature protection and other functions, maximize the elimination of safety hazards;

5.The battery pack has nice safety, good discharge performance and long cycle life;

6.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.

*
*
*
*
*
