14.4V 13000mAh 18650 Ternary Battery with SMBUS Communication for Intelligent Household Robot

Product number: 02KQ0011-02T

Cell model: LR1865SK/2600mAh/3.6V

The battery specification: LR1865SK / 4 s5p / 13000 mah / 14.4 V

Nominal voltage: 14.4V

Nominal capacity: 13Ah

Charging voltage: 16.8V

Charging current: ≤5.0A

Discharge current: ≤6.0A

Instantaneous discharge current: 8.0A for 1S

Discharge cut-off voltage: 11.0V

Finished product internal resistance: 200 mΩ or less

Battery weight: about 980g

Product dimension: 190*71*38mm (Max)

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60 ℃

Storage temperature: -20 ~ 35 ℃

Temperature protection: charge 55±2℃ discharge 60±2℃

Battery case: PVC

Lithium battery protection: overcharge protection, overdischarge protection, overcharge and discharge current protection, charge and discharge short circuit protection, charge and discharge temperature protection, low voltage alarm, etc.

Application: Home intelligent robot

Product features

1.Data communication management SMBUS: TI software and IC monitoring is used to manage temperature, voltage, capacity, percentage and other parameters in the battery pack.

2.The host machine transmits data through SMBUS communication, so that the battery pack information can be understood at any time to improve security.

3.Battery pack cycle life is high, in line with the low carbon, energy saving, environmental values.
