7.4V/1200mAH Lithium-ion Battery for Portable Device

Project number: 40DZ009-03

Cell model: 784040/1200mah /3.7V

Specification: 2S1P/1200mAh/7.4V (low temperature)

Nominal voltage: 7.4V

Nominal capacity: 1200mAh

Charging voltage: 8.4V

Charging current: ≤0.6A

Discharge current: 2.4A

Instantaneous discharge current: 3-5A

Discharge cut-off voltage: 5V

Product internal resistance: ≤200mΩ

Battery weight: 45G

Product size: 19.2*41*42mm (Max)

Charging temperature: 0 ~ 45℃

Discharge temperature: -40 ~ 60 ℃

Storage temperature: -40 ° C to 45 ° C

Battery case: PVC

Communication: no

Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection,SMBUS communication, etc.

Application: Portable devices

Product Features

1.Energy consumption is low;

2.Communication management: Use TI software to manage chips, transmit data precisely and control temperature, so as to minimise security risks.

3.The battery pack is safe, has good low-temperature performance and long cycle life.

4.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
