655375 3.7V 6200mAh Lithium Polymer Battery Pack for Security and Monitoring

Project number: 01DQ0023-55

Cell model: 655375/3100mah /3.7V

Battery specification: 655375-1S2P/6200mAh/3.7V

Nominal voltage: 3.7V

Nominal capacity: 6200mAh

Charging voltage: 5V charging

Charging current: ≤ 3.1A

Discharge current: 3.1A

Instantaneous discharge current: 10.0A

Discharge cut-off voltage: 3.0V

Internal resistance: ≤250mΩ

Battery weight: 150g

Product size: 16.2*60.4*93.9mm

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 55℃

Storage temperature: 0 to 25°C

Intelligent lithium battery protection: charging management, short circuit protection, over charge protection, over discharge protection, over current protection, etc.

Application: Security monitoring
