26650 38.4V 32.4Ah Lithium Iron Phosphate Battery Pack Mobile Car RS485 Communication

Product number: 01DQ0155-01

Cell model: 26650-3600mAh-3.2V

Battery specification: 26650-12S9P-32.4Ah-38.4V

Product size: 300±1mm *220± 1mm *125±1mm

Nominal voltage: 38.4V

Nominal capacity: 32.4Ah

Charging voltage: 43.2V

Charging current: 10A

Discharge current: 5A

Discharge cut-off voltage: 24V

Finished internal resistance: ≤200mΩ

Battery weight: 13.5Kg

Charging temperature: 0 ~ 45℃

Discharge temperature: -20~+60℃

Storage temperature: -20°C ~45°C (less than 1 month) -20 ~ 35 °C (less than 3 months); -20~+25℃ (less than 6 months)

Battery package: stainless steel sheet metal shell (natural color) + folding handle

Lithium-ion battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, overtemperature protection, etc.

Application: mobile car

Product Features:

1.Sheet metal shell process is simple and reliable, and is easy to install.

2.RS485 communication protocol

3.Output terminal: Adopt the national standard UL wire output mode to increase the electrical reliability;

4.Battery protection management: Use imported well-known brand protection chip with nice stability, high precision monitoring, precise control, to eliminate security risks.

5.The battery pack has nice safety, good discharge performance and long cycle life;

6.The battery pack has long cycle life, in line with low carbon, energy saving, environmental protection value concept.
