11.1V 5200mAh LARGE Battery Ternary Battery Lithium Polymer Battery for Instrument Equipment

Product number: 01DQ0107-04

Cell model：8547104-11.1V-5200mAh

Battery specification: 8547104-3S1P-5200mAh-11.1V

Nominal voltage：11.1V

Nominal capacity：5200mAh

Charging voltage: 12.6V

Charging current: ≤1.5A

Discharging current: 5.0A

Instant discharging current: 6.0A

End-off voltage: 8.25V

Internal resistance: ≤220mΩ

Battery weight: 280g

Product dimension: 120.0×50.0×29.0mm（max）

Charging temperature：0～45℃

Discharging temperature: -20～60 ℃

Storage temperature: -20～45℃

Battery case: general industrial grade

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection, etc.

Application field: instrument equipment

Product features

1. Communication protocol: SMBUS communication protocol can transmit product data.

2. Cell characteristics: power type ternary battery pack

3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
