442253 7.6V 560mAh Lithium Polymer Battery for Medical Device

Product number: 37DZ071-02

Cell model: 442253/3.8V/560mAh

Battery specification: 442253-2S1P-560MAH-7.6V

Nominal voltage: 7.6V

Nominal capacity: 560mAh

Charging voltage: 8.7V

Charging current: ≤300mA

Discharge current: ≤1000mA

Instant discharge current: 3-6A

Discharge cut-off voltage: 6V

Internal resistance of finished product: ≤200mΩ

Battery weight: 16G

Product dimension: 55*23*16mm (L*W*H)

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60℃

Storage temperature: -20 ~ 45℃

Battery case: PVC

Lithium-ion battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, charge management, etc.

Application: medical portable devices

Product features

1.It has CC-CV charging management circuit;

2.Cell: Use ultra-safe polymer cell, which can be discharged in -20 degrees environment;

3.The battery pack has good safety, low temperature performance and long cycle life;

4.The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
