18650 3.65V 2600mAh Lithium-ion Battery for Portable IVD

Product number: 05DQ0065-02

Cell model: 18650-2600mAh-3.65V

Battery specification: 18650-1S1P-2600mAh-3.65V

Product size: 71*19.5mm (Max)

Nominal voltage: 3.65V

Nominal capacity: 2600mAh

Internal resistance of finished product: ≤180mΩ

Charging voltage: 4.2V

Charging current: ≤1.25A

Discharge current: ≤1.25A

Discharge cut-off voltage: 3.0V

Battery weight: 50g

Charging temperature: 0 ~ 45℃

Discharge temperature: -20 ~ 60 ℃

Storage temperature: -20 ~ 35 ° C

Battery package: Blue PVC heat shrinkable film

Output mode: MOLEX plug

Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection,ESD protection, etc.

Application: Portable IVD products, portable equipment
